Replacing the battery case
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Align the screw holes on the battery case with the screw holes on the chassis.
2. Replace the two screws (#6-32x5.2) that secure the battery case to the chassis.
3. Connect the battery-case cable to the I/O board.
Post-requisites
1. Replace the
battery.
2. Replace the right side-panel. See “Replacing the side panels”.
3. Replace the stability foot.
