Replacing the side panels
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
Procedure
1. Align the tabs on the right side-panel with the slots on the right side of the computer and snap the panel to lock it in place.
2. Repeat step 1 to replace the left side-panel.
3. Slide and hold the security-cable slot latch in the locked position.
4. Replace the screw (M2x3) that secures the security-cable slot latch.
23
