Replacing the front bezel
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Align the tabs from inside the chassis on the right and left side and place the front bezel and snap it in place.
2. Connect the top tron light-cables to the front bezel.
3. Connect the bottom tron light-cables to the front bezel.
4. Replace the screw (6-32x5.2) from inside, securing the front bezel to the right side of the chassis.
5. Replace the two screws (6-32x5.2) from inside, securing the front bezel to the left side of the chassis.
6. Replace the four screws (#6-32x6) that secure the front bezel to the bottom and top of the chassis.
Post-requisites
1. Replace the
handle bars.
2. Replace the left and right side-panels. See “Replacing the side panels”.
3. Replace the stability foot.
98
