Replacing the top tron-lighting cable
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the steps
in Before working inside your computer. After working inside your computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/regulatory_compliance.
Topics:
• Procedure
• Post-requisites
Procedure
1. Align and place the top tron-lighting cables on the chassis.
2. Adhere the tape that secures the top tron-lighting cables to the chassis.
3. Route the top tron-lighting cables through the routing-guides on the chassis.
4. Connect the top tron-lighting cables to the logo board.
Post-requisites
1. Replace the
base panel.
2. Replace the rear bezel.
3. Replace the
front bezel.
4. Replace the handle bars.
5. Replace the left and right side-panels. See “Replacing the side panels”.
6. Replace the stability foot.
