Figure 61. Installing the power button
Steps
1. Insert the power-button cable in the slot on the chassis from the front-side of the computer, and press the power-button
head until it clicks into the place in the chassis.
2. Connect the power-button cable to the connector (PWR SW) on the system board.
Next steps
1. Install the front bezel.
2. Install the side cover.
3. Follow the procedure in After working inside your computer.
Wireless antenna kit
Internal antenna module
Removing the internal antenna module
CAUTION: The information in this removal section is intended for authorized service technicians only.
90 Removing and installing Field Replaceable Units (FRUs)
