Next steps
1. Reconnect all the cables to the 1GbE mezzanine card.
2. Replace the system board assembly.
3. Reconnect the peripherals and connect the system to the electrical outlet.
4. Turn on the system, including any attached peripherals.
Related Links
Safety instructions
Installing the system board assembly
Removing the 10GbE mezzanine card
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
NOTE: The 10GbE mezzanine card is seated in PCI-E Gen3 x8 mezzanine slot 3 on the system
board, which is not active in 1-processor configuration. See the C6320 system board connectors
section.
1. Follow the safety guidelines listed in the Safety instructions section.
2. Turn off the system, including any attached peripherals.
3. Disconnect the system from the electrical outlet and disconnect the peripherals.
4. Remove the system board assembly.
Steps
1. Disconnect all the cables from the 10GbE mezzanine card.
2. Remove the screws that secure the expansion card bracket.
3. Lift the expansion card bracket out of the system board assembly.
108
