Item Cable From (LSI 2008 SAS Mezzanine
card)
To (System board)
On LSI 2008 SAS Mezzanine Card
Mini-SAS connector 0-3 (J3)
On LSI 2008 SAS Mezzanine Card
Mini-SAS HD Connector 0-3
MicroSATA
cable
1.8-inch SSD Onboard SATA Connector 5 on the
system board
1.8-inch SSD DC to DC board (J2)
1x4 power
cable
DC to DC to DC board (J1) High Power Connector on the
system board
SATADOM
Removing the SATADOM
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
1. Follow the safety guidelines listed in the Safety instructions section.
2. Turn off the system, including any attached peripherals.
3. Disconnect the system from the electrical outlet and disconnect the peripherals.
Steps
1. Disconnect the power cable from the SATADOM and the system board.
2. Using a screwdriver, press the metal latch to release the SATADOM.
3. Holding the SATADOM by its edges, pull the SATADOM until the card edge connector disengages
from the onboard SATA connector 5 on the system board.
