Figure 16. Removing the system cover
Next steps
1. Install the system cover.
Installing the system cover
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working on your system.
Steps
1. Align the tabs on the system cover with the guide slots on the system.
2. Close the system cover release latch.
3. Using a 1/4-inch flat head or Phillips #2 screwdriver, rotate the lock clockwise to the lock position.
NOTE: The numbers on the image do not depict the exact steps. The numbers are for representation of sequence.
52 Installing and removing system components
