124
Dell™ Printer Configuration Web Tool
SNTP
Purpose:
To configure the SNTP server settings in order to perform time synchronization through SNTP.
Va lu e s:
AirPrint
Purpose:
To configure the detailed setting of AirPrint.
Va lu e s:
Google Cloud Print
Purpose:
To register the printer to Google Cloud Print.
Va lu e s:
SNTP IP Address / Host Name Sets the IP address or the host name of the SNTP server.
Connection Time-Out Sets the connection time-out period from 1 to 120 seconds.
Time Synchronization
Interval
Sets the interval for performing time synchronization using SNTP.
Last Connection Time Displays the last date and time when your printer was connected to the
SNTP server.
Connection Status Displays the status of the connections between the SNTP server and your
printer.
AirPrint Enable AirPrint Click to enable the printer for AirPrint.
Bonjour Name Enters the name that is to be displayed as an AirPrint
printer.
Location Sets the location of the printer.
Geo-Location Sets the physical location of the printer.
IPP Authentication Basic Authentication Select the check box to enable the basic authentication
scheme.
User Name Enter the user name.
Password Enter the user password.
Re-enter Password Re-enter the user password for confirmation.
SSL/TLS SSL/TLS Click Settings to display the SSL/TLS page.
Supply Levels Toner Cartridge Displays the toner level.
Google Cloud Print
*1
(Registration state) Displays the Google Cloud Print registration state.
Register This Device to
Google Cloud Print
Click to register the printer to Google Cloud Print.
Cancel Registration Click to cancel to register the printer to Google Cloud Print.
*1
Google Cloud Print can only be used when the machine is using IPv4.

Table of Contents

Other manuals for Dell S2810dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell S2810dn and is the answer not in the manual?

Dell S2810dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeManual
Time to first page (black, normal)7 s
Print speed (black, normal quality, A4/US Letter)35 ppm
Duplex print speed (black, normal quality, A4/US Letter)22 ppm
Printing colorsBlack
Maximum duty cycle40000 pages per month
Recommended duty cycle500 - 3000 pages per month
Number of print cartridges1
Page description languagesPCL 5e, PCL 6, PDF 1.7, PostScript 3, XML
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity350 sheets
Envelopes sizesC5, DL, Monarch
Maximum print size216 x 356 mm
Paper tray media typesPlain paper, Pre-Printed, Recycled paper, Thick paper
Paper tray media weight60 - 80 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Wi-Fi-
Security algorithms802.1x RADIUS, EAP-MD5, EAP-PEAP, HTTPS
Mobile printing technologiesApple AirPrint, Dell Mobile Print, Google Cloud Print
Supported network protocols (IPv4)HTTP, TCP, UDP, ICMP/IGMP, BOOTP, DHCP, RARP, Auto IP, WINS, DNS, Bonjour(mDNS), Telnet
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Memory typeDDR3
Maximum internal memory- MB
Sound power level (standby)24.7 dB
Sound pressure level (printing)53.4 dB
DisplayLCD
CertificationCE, FCC
Display number of lines4 lines
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)45 W
Power consumption (printing)560 W
Mac operating systems supportedMac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)15 - 85 %
Package depth545 mm
Package width528 mm
Package height414 mm
Package weight14600 g
Weight and Dimensions IconWeight and Dimensions
Depth438 mm
Width410 mm
Height273 mm
