5.5. STG: Strain Gauge Module
IOLITE STG can be found in the following options:
- IOLITE 6xSTG slot slice
- IOLITE 6xSTG single slice
- IOLITEi 1xSTG single channel slice
5.5.1. IOLITE-6xSTG
IOLITE 6xSTG modules have universal 6 channel differential voltage, current and Full / Half / Quarter
bridge input with DSUB-9 connector. Compatible with DSI adapters for IEPE, CHG, 200 V, RTD, TH
measurements.
IOLITE-6xSTG module
5.5.2. IOLITEi-1xSTG
IOLITEi-1xSTG is a single channel strain gauge amplifier with internal quarter, half and full-bridge
configurations. Low noise voltage and current source excitation are available with freely settable levels.
Input ranges span from 50V to 100mV. Data transferred over the EtherCAT to a PC running powerful and
easy to use.
