DEWESOFT IOLITE User Manual

IOLITE®
TECHNICAL REFERENCE MANUAL
5.9.3. AO: Specifications
IOLITE-16xAO
Analog Output
Output types
Voltage
Number of channels
16
Output connector
Terminal block
DAC Resolution
16-bit
Update Rate
20000 S/sec (see 1)
Full Scale Output Range
±10 V (see 2)
Accuracy (typ.)
0.05 % ±1.5 mV (0 to 20 mA load)
Temperature gain drift (typ.)
±10 ppm/K
Temperature offset drift (typ.)
±5 uV/K
Output impedance
< 1 Ω DC
Minimal load resistance
500 Ω load @ 10 V output
Settling time (0.05 % of set value)
140 µs
Max slew rate
0.20 V/µs
Max capacitive load (2 % overshoot)
10 nF
Output protection
Short circuit protected
Current limit
20 mA per channel (160 mA per module)
Isolation
Channel to ground
Additional Specifications
Output connectors
Terminal block, 2 pole, 4 x 9 pole
OMNIMATE SL 2.50 / BLF 2.50/180
Power supply
12 - 48 V DC
Power out
max. 2 A
Power consumption
Typ. 4.3 W, Max. 7.2 W
Weight
210 g
Slice Dimensions
128.4 x 115.4 x 30.1 mm
Rev: 1603360800
1) Only asynchronous mode is supported in Dewesoft, function generator is not supported
2) Only DC output voltage, function generator not supported
IOLITE® V20-1 128/153
