5.2.4.2. IOLITEi-8xLV: BNC Connector: Pin out
LV connector: pin-out (BNC)
Pin
Name
Description
1
IN+
Analog input
2
GND
Ground
5.2.4.3. LV: BNC Connector: Wiring diagram
5.2.4.3.1. LV: Voltage
