5.9.4. IOLITE 16xAO: Terminal block Connectors
IOLITE-16xAO Front
5.9.4.1. IOLITE-16xAO: TBLOCK Power Connector: Pinout
LV connector: pin-out (TBLOCK male)
Pin
Name
Description
1
IN+
Analog input +
2
IN-
Analog input -
Connector (on the device): OMNIMATE Signal SL 2.50/02/90G
Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180
