IOLITE®
TECHNICAL REFERENCE MANUAL
List of required cables:
Function
Dewesoft order code
Power supply
Sirius: PS-120-L1B2f (default)
Sirius to IOLITE: L1B2m-L1B2f-0.2m,
L1B2m-L1B2f-0.4m, L1B2M-L1B2F-3m
EtherCAT
IOLITE to PC: L1T8f-RJ45-1M (default),
L1T8f-RJ45-3M, L1T8f-RJ45-5M
USB
CABLE-USBAmini-USBBS-1.8m (default),
CABLE-USBAmini-USBBS-1m
Synchronization
L00B4m-L00B4m-0.2m (default),
L00B4m-L00B4m-0.5m, L00B4m-L00B4m-3m
4.3.2.7. IOLITE-R8: Boxed Chassis: Connection of IOLITE multi and single channel device
Connect power supply cable to IOLITE-R8 (PS-120W-L1B2f).Then connect L1T8f-RJ45-1M cable (LEMO
side) to IN connector of BUS 1 on IOLITE-R8 back panel.
Use the L1T8m-RJ-45 cable to connect the IOLITE - single channel device. An additional power cable is
not needed, as the device can power over Ethernet cable.
Use a RJ-45 - RJ-45 cable to connect the IOLITE - multichannel device. An additional Power supply is
needed for the device with the cable.
IOLITE® V20-1 51/153
