DEWESOFT IOLITE User Manual

IOLITE®
TECHNICAL REFERENCE MANUAL
Interface
IOLITEi Single channel
Data interface
EtherCAT
Data Rate
100 Mbps Full Duplex bus speed
Synchronization
1 µs
Bus connectors
Ethernet RJ45
Max. cable length between
devices
100 m
Max. Throughput per Chain
From 6 MB/s to 10 MB/s
Max. Number of Units
55 per chain (@ 20 kS/s total sample rate per device), multiple chains possible. Additional power
injectors are necessary.
Data interface connection
Ethernet RJ45, Single cable for data, power and sync, daisy chainable
Power
Power supply
12 V - 48 V
Power consumption
~2 W (see individual modules)
Environmental
Operating Temperature
-20 to 60 °C
Storage Temperature
-20 to 60 °C
Humidity
95 %, no condensation
IP rating
IP20
Physical
Dimensions
82 mm x 62 mm x 52 mm (might differ for different modules)
Weight
130 g (might differ for different modules)
