Preparing the Machine
13
When changing to a cutting tool with the same shank diameter
CAUTION
 Donottouchthetipofthecuttingtoolwithyourngers.
Doing so may result in injury.
Procedure
1. Loosen the set screw with hexagonal wrench.
Support lightly by hand not to drop a cutting tool.
2. Remove the cutting tool.
3. Attach the cutting tool which you want to use ,and tighten the set
screw.
When changing to a cutting tool with a dierent shank diameter
Procedure
1. Remove the collet from machine.
Refer to the procedure 4 to 5 of “STEP 5 : Attach the Cutting Tool”
(p. 11) in revers order, remove the collet.
2. Attach the cutting tool.
Refer to the procedure of “STEP 5 : Attach the Cutting Tool” (p. 11),
attach the cutting tool.
