Cutting (Double Sided)
58
5. On the menu bar of SRP Player, click [Options] [Hole...].
6. Congure the positioning pin diameter, the number of holes, and
other settings as appropriate.
This example assumes that the following options are congured:
• Pin Diameter : 3 mm
• Adjust Hole Diameter : Set the slider to [Pin Dia.].
• No. of Holes : 2
• Depth : 5 mm
• Tool : 2 mm Square
• Material : Chemical Wood (Soft)
• Cutting Direction : Up Cut
When you are done, click
.
