24/ SETUP
OPERATOR'S MANUAL
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
8. Split Row Configuration
For users that utilize split, twin, or skip
row type seeding implements, this feature
will allow easy configuration for setting
up the correct row pattern that is used.
Reference Figure 15 for a listing of all of
the row patterns that can be applied to
the system. When a row pattern is
selected, all of the rows are automatically
turned ON or OFF according to the
pattern. The user can still edit individual
rows in the Row Configuration Screen,
but it can only be done after a pattern is
selected. Figure 16 shows a row pattern
of 01 being selected.
Split Row
Configuration Description/Example
00 All Rows On
01 Every other Row Off, with first Row On (OXOXOX)
02 Every other Row Off with first Row Off (XOXOXO)
03 Every Third Row On (OXXOXXOXX)
04 Every Third Row On (XXOXXOXXO)
05 Every Third Row On (XOXXOXXOXX)
06 Every Third Row Off (OOXOOXOOX)
07 Every Third Row Off (OXOOXOOXOO)
08 Every Third Row Off (XOOXOOXOO)
09 Every Fourth Row On (OXXXOXXXOXXX)
10 Every Fourth Row On (XXXOXXXOXXXO)
11 Every Fourth Row On (XXOXXXOXXXOXXX)
12 Every Fourth Row On (XOXXXOXXXOXXX)
13 Twin Rows (OOXXOOXXOOXX)
14 Twin Rows (OXXOOXXOOXXOO)
15 Twin Rows (XXOOXXOOXXOO)
16 Twin Rows (XOOXXOOXXOOXX)
17 Every Fourth Row Off (OOOXOOOXOOOX)
18 Every Fourth Row Off (OOXOOOXOOOXOOO)
19 Every Fourth Row Off (OXOOOXOOOXOOO)
20 Every Fourth Row Off (XOOOXOOOXOOO)
Figure 15
