64/ TROUBLESHOOTING
OPERATOR'S MANUAL
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
ERROR CODE E21
Too Many Shaft Modules are connected to the System
Probable Cause
System Contains incorrect parts (multiple Shaft Modules)
Corrective Action
Disconnect any additional Modules that are connected. Disconnect one module at a
time to determine which module is incorrect.
ERROR CODE E30 X
Too Few Seed Sensors are connected to Module X (X is the number of the module,
and Modules are numbered from the far Left side of the implement to the far Right
side of the implement).
Probable Cause
1. Failed Seed Sensors
2. Number of Seed Sensors for Module X Configuration is Incorrect.
3. Seed Sensors not connected sequentially
4. Implement Harness is not connected to all Seed Sensors.
5. Harnessing cut and/or pinched
Corrective Action
1. Contact DICKEY-john Technical Support for a replacement sensor. See inside,
back cover of this manual for phone number.
2. Check the Number of Seed Sensors for Module X Configuration in SETUP
MODE with the actual number of Seed Sensors connected.
3. Seed Sensors on each module must be connected from the lowest to highest row
inputs without skipping rows.
4. Check harness connection to sensor number that corresponds with the number
in the lower display.
5. Locate the fault and repair wires by splicing, soldering, and sealing wires.
