54/ ALARM
OPERATOR'S MANUAL
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
7. Fan Speed Lo Limit Warning
This occurs when any fan speed falls
below the value entered for Fan Speed
Lo Limit in the SETUP MODE. The
alarm beeps for three (3) seconds and
the fan speed sensor number and actual
fan speed, in RPM, are displayed. If
multiple fan speed sensors fall below the
limit, the fan speed sensor numbers are
displayed sequentially, along with their
respective fan speeds. Figure 59 shows a
Fan Speed Lo Limit Warning on fan
speed sensor two (2) with a fan speed of
167 RPM.
Figure 59
FAN SPEED LO LIMIT Warning Display
8. Shaft Speed Hi Limit Warning
This occurs when any shaft speed
exceeds the value entered for Shaft
Speed Hi Limit in the SETUP MODE.
The alarm beeps for three (3) seconds
and the shaft speed sensor number and
actual shaft speed, in RPM, are dis-
played. If multiple shaft speed sensors
exceed the limit, the shaft speed sensor
numbers are displayed sequentially,
along with their respective shaft speeds.
Figure 60 shows a Shaft Speed Hi Limit
Warning on shaft speed sensor one (1)
with a shaft speed of 1,592 RPM.
Figure 60
SHAFT SPEED HI LIMIT Warning Display
