OPERATOR'S MANUAL
SETUP/ 33
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
24. Pressure Sensor Lo Limit
The Pressure Sensor Lo Limit Warning
is entered in oz/in
2
(kPa). The Hi and
Lo warning limits are accessible only if
the Number of Pressure Sensors has a
value other than 0. Setting the Pressure
Sensor Lo Limit will cause the audible
alarm to sound when the pressure falls
below the value that has been entered.
Use the SET and SELECT switches to
adjust the Pressure Sensor Lo Limit
value. The Pressure Sensor Lo Limit
can be enabled or disabled by selecting
the ON or OFF symbol after the
rightmost digit. Pressing the SET switch
will toggle the status of the warning
between ON and OFF. Figure 32 shows
a Pressure Sensor Lo Limit of 3.8 with
the warning disabled.
25. Blockage Mode Configuration
This configuration will select one of
three different modes according to the
Table in Figure 33. If Mode 0 or Mode
1 is selected, the Operate screens will
cycle through the Population Rows only.
If Mode 2 is selected, The Population
and Spacing Operate screens will show a
series of 5 dashes to represent no data.
Figure 32
Lo Limit Pressure Display
Figure 33
Blockage Configuration
Blockage
Mode Description
0 All Rows are configured for displaying Population
1 First Row of each Module is configured for displaying
Population – All other rows are configured for
Blockage Only.
2 All Rows are configured for Blockage Only
