OPERATOR'S MANUAL
TROUBLESHOOTING/ 63
Dj SEED MANAGER® SE PLANTER MONITOR
BENCHMARK Series® 11001-1218-200112 Rev A
Corrective Action
1. Check the Number of Seed Modules Configuration in SETUP MODE with the
actual number of modules connected.
2. Check harness connection after the module number associated with number in
lower display.
3. Locate the fault and repair wires by splicing, soldering, and sealing wires.
4. Exchange module after the module number associated with number in lower
display and reapply power to the console. If the same exact error code and lower
digit number is displayed then the module number associated with the lower
display is defective. If the lower digit changes then the module that was replaced
was defective.
ERROR CODE E11
Too Many Seed Modules are Connected
Probable Cause
Number of Seed Modules Configuration is incorrect
Corrective Action
Check the Number of Seed Modules Configuration in SETUP MODE with the
actual number of modules connected
ERROR CODE E20
Too Few Shaft Modules are connected to the System.
Probable Cause
1. Number of Fan, Shaft, or Pressure Sensors Configuration is incorrect.
2. Ground Speed input Source is set incorrectly to d2.
3. Implement Harness not connected to Shaft Speed Module
4. Harnessing cut and/or pinched
5. Defective Module
Corrective Action
1. Check the Number of Fan, Shaft, and Pressure Sensor Configuration in SETUP
MODE with the actual number of sensors connected
2. Check the Ground Speed Sensor Configuration in SETUP MODE with the
actual ground speed sensor connected
3. Check harness connection before and after the Shaft Speed Module.
4. Locate the fault and repair wires by splicing, soldering, and sealing wires.
5. Contact DICKEY-john Technical Support. See inside, back cover of this manual
for phone number.
