Digi DP-5000 - Basic Cleaning; Dismantled Thermal Head

DI-5000_DP-5000_DPS-5000 Service Manual Edition 2
72
4. After cleaning, push back the printer front cover into the main unit.
5. Turn ON the scale, and depress [FEED] key to feed label.
7.7.2 Basic Cleaning
Clean scale surfaces periodically with a soft damp cloth. Do not use alcohol or detergent.
7.7.3 Dismantled Thermal Head
Note: Please ensure switch “OFF” the machine power.
1. Pull out the Label Drawer to forward in half way.
(Note: Do not pull out fully to forward)
2. Press down the thermal head from top.
3. Push to behind the catch of thermal head bracket.
4. Disconnect cable and remove the Thermal Head.
