Digi DP-5000 - 8 Firmware Upgrading; Kernel

DI-5000_DP-5000_DPS-5000 Service Manual Edition 2
74
8. FIRMWARE UPGRADING
8.1 Kernel
Procedure Picture
1) At PC screen, click [Start]  [All Programs]  [Accessories] 
[Communication]  [Hyper Terminal].
2) Keying the any name (e.g. DP-5000) and click [OK].
3) Select the [COM 1] and click [OK].
DP-5000 machine
RS-232 downloading cable
RS-232
(
COM 1
)
AC Inlet
PC
