15 EVOLUTION 1 SYSTEM MANUAL Issue 1.1 20 Dec 2006
EVOLUTION II QUICK START
Connect the printer carriage to the appropriate
power source.
Connect the controller to the carriage assembly.
The controller derives power from the carriage.
On startup the LCD will display as pictured.
CHANGING LANGUAGE PROMPTS
Press the F4 key and select for
LANGUAGE. Use the keys to select the
desired language and press the
to select the
language.
ENABLING PRINT MODE
Press the GREEN PRINT key to start printing
HEAD SELECT MODE
The hand held controller can program up to 32 print
carriages on an RS485 data link. The factory default
sets each print carriage to ADDRESS 1. Selection
of another print head other than ADDRESS 1, press
the
key. Use the keys to select the
alternate print carriage number and press the
key. The print carriage whose address was selected
will respond with the current message and
appropriate parameters.
As an added convenience using the will auto scan to find the next
available head connected to the environment
Accessing an address not associated with any print
carriage will result in a no response message.
EV2 STOPPED
HD 1- - >SPEED=100
EVOLU
< - - SELECT - - >
ENGLISH
EV2 PRINTING
HD 1- - >SPEED=100
EVOLU
EV2 STOPPED
HD 1- - >SPEED=100
EVOLU
< - - SELECT - - >
WHICH HEAD = 1
EVOLU
NO RESPONSE
ANY KEY TO EXIT
