1 EVOLUTION 1 SYSTEM MANUAL Issue 1.1 20 Dec 2006
PART 3: MAINTENANCE PROCEDURES
SHORT PERIODS OF SHUT DOWN
When the printer has been shut down overnight, the system might require a
purge to clear out dust particles that have settled on the nozzle area during non-
use. This is only necessary if there are missing dots in the printed code on
product.
To purge be sure that the unit is in the STOPPED
Mode by pressing green key. The screen
changes to STOPPED as shown to left.
Place a piece of lint free wipe (or absorbant paper)
in front of the print head and press the red .
Allow the unit to purge for several seconds. There is
an automatic shut down after 1,000 printed columns
to ensure that the print head will not be damaged. If
ink residue has solidified on the nozzle area a small
drop of water may be applied to the lint free wipe.
When purging is complete the LCD will be returned
to the STOPPED mode.
Press the green and the screen changes to
PRINTING, as shown at the left. The unit is ready
to begin coding.
STOPPED
HD1- - >SPEED=120
EVOLUTION 1
PURGING
HD1- - >SPEED=120
EVOLUTION 1
STOPPED
HD1- - >SPEED=120
EVOLUTION 1
PRINTING
HD1- - >SPEED=120
EVOLUTION 1
