3 EVOLUTION 1 SYSTEM MANUAL Issue 1.1 20 Dec 2006
TURNING ON THE PRINT STATION FOR THE FIRST TIME
To turn the print station on insert the power jack into
the DC power connector.
There is no on/off switch.
The first time the print station is turned on, as
received from the factory, the LCD will look like the
illustration on the left. Each line gives important
information regarding the system:
The Top line indicates the operating mode of the
unit: STOPPED when in Command mode, PRINTING when in Print mode, and
MESSAGE ENTRY when in message entry.
The 2
nd
line shows the print head currently selected, the direction of travel for the
product and the programmed SPEED.
The lower half of the display shows the message entered for printing. This may
represent one, two, three or four lines of code.
NOTE: THE DISPLAY IS A WYSWIG GRAPHIC TYPE AND MAY
ONLY DISPLAY A PORTION OF THE ACTUAL MESSAGE.
CHECKING SYSTEM INFORMATION
Verify system information by pressing the V key
on the hand held controller keyboard. The LCD
screen will display the software, firmware, serial
number and options enabled. The EVOLUTION
II printer is fully configured thus a ++++ will be
displayed.
CHECKING LOADED FONTS
Press the FONT
key in the COMMAND
mode to check what fonts are currently loaded
in the print head.
EV2 STOPPED
HD1- - >SPEED=120
EVOLU
CONTROLLER 1.06
PRINTER 2.08K++++
PRINTER SN284955
ANY KEY TO EXIT
EVSC ACTIVE FONTS
4 LINE ARIALA332
3 LINE ARIALA1_8
2 LINE ARIALA732
1 LINE ARIALA1_2
ANY KEY TO EXIT
