10 EVOLUTION 1 SYSTEM MANUAL Issue 1.1 20 Dec 2006
3 = DATE OFFSET:
To enter a date offset (expiration date) change the
value equal to the number of days until expiration.
Legal entries are 0 to 999 days. The format of the
date offset can be different than a normal date and
may be set with the F3 #3 option DATE FORMAT.
4 = BARCODE TYPE:
This parameter determines the barcode type to be
entered into a message. As standard the
EVOLUTION II contains 8 barcode symbologies,
which are: UPC-A, UPC-E, EAN-8, EAN-13, CODE
39, CODE 128B, CODE 128C AND INTERLEAVED
2 OF 5.
Press or to change the barcode type and
press once the desired type is displayed.
The default system parameter establishes that the
normal size of a narrow bar is equal to 5 vertical
columns. This value, which is variable from 3 to 15,
is selectable depending on the overall length of the
barcode to be printed. This value sets both the light
and dark bars nominal width.
The added space parameter allows the user to
insert extra columns to a normal light bar width to
allow for the bleed factors associated with various
substrates. Valid entries are from 0 to 3 extra
spaces.
The quiet zone is the space before and after a
barcode that must be kept blank. Each count is
equal to one vertical column. In proper aspect ratio
each column is 0.0033” thus a count of 75 would
leave 0.247” before and after the barcode.
Check digits may be added to any of the imbedded
symbologies by selecting option 1.
DATE OFFSET
USE KEYS 0->9
# OF DAYS = 100
< - - SELECT - - >
CODE 39
< - - SELECT - - >
UPC A
< - - SELECT - - >
MIN. BAR WIDTH= 5
< - - SELECT - - >
ADDED SPACE = 0
< - - SELECT - - >
QUIETZONE WIDTH 75
ADD CHECK DIGIT
1 = YES
2 = NO
To Next Page
