9 EVOLUTION 1 SYSTEM MANUAL Issue 1.1 20 Dec 2006
GROUNDING STRAP INSTALLATION
INPUT POWER CONNECTION AND MODIFICATION
Insert the power plug to the available power source. The supplied power supply
will is universal and will auto detect 100/240 VAC 50-60hZ.
No other adjustments are necessary.
INSTALL STRAP
UNDER 5/16”
SCREW. ENSURE
CONDUCTIVITY TO
EARTH GROUND IS
LESS THAN 1 OHM
