2 EVOLUTION 1 SYSTEM MANUAL Issue 1.1 20 Dec 2006
EVOLUTION CONTROLLER
GRAPHIC
(WSYWIG)
LCD DISPLAY
EVOLUTION
CONTROLLER
KEYBOARD
PRINT HEAD
CABLE PLUG
NOTE:
THE EVOLUTION
GRAPHIC CONTROLLER
WILL CONTROL THE
EVOLUTION 1 (EV1)
EVOLUTION 2 (EV2)
EVOLUTION SC (EVSC)
THE UPPER LEFT
CORNER OF THE DISPLAY
INDICATES THE SPECIFIC
PRINTER CONNECTED TO
THE HAND HELD
CONTROLLER
EV2 STOPPED
HD 1<- - SPEED= 120
EVOLUTION CODERS
EVOLU
