Digital Projection E-Vision 6800 3D Series
Connection Guide
SUPPORTED SIGNAL INPUT MODES
Rev A January 2015
Signal Resolution Refresh Rate
( Hz )
Total
number
of lines
Horizontal
Frequency
(kHz)
VIDEO /
S-VIDEO
Component
1 & 2
VGA
HDMI /
HDBaseT
DVI (DVI-D)
COMPUTER VGA59 640 x 480 59.94 525 31.47
ü ü ü
VGA60 640 x 480 60.00 525 31.50
ü ü ü
VGA75 640 x 480 75.00 500 37.50
ü ü ü
SVGA60 800 x 600 60.32 628 37.88
ü ü ü
SVGA75 800 x 600 75.00 625 46.88
ü ü ü
SVGA85 800 x 600 85.06 631 53.67
ü ü ü
XGA60 1024 x 768 60.00 806 48.36
ü ü
XGA70 1024 x 768 70.07 806 56.48
ü ü
XGA75 1024 x 768 75.03 800 60.02
ü ü
WXGA50 1280 x 720 49.83 744 37.07
ü ü
WXGA60 1280 x 768 59.87 798 47.78
ü ü
WXGA75 1280 x 768 74.89 805 60.29
ü ü
WXGA85 1280 x 768 84.84 809 68.63
ü ü
WXGA60 1280 x 800 59.81 831 49.70
ü ü ü
SXGA60 1280 x 1024 60.02 1066 63.98
ü ü ü
SXGA75 1280 x 1024 75.02 1066 79.98
ü ü ü
SXGA85 1280 x 1024 85.02 1072 91.15
ü ü ü
SXGA+60 1400 x 1050 59.98 1089 65.32
ü ü ü
UXGA60 1600 x 1200 60.00 1250 75.00
ü ü ü
WSXGA+60 1680 x 1050 59.95 1089 65.29
ü ü ü
FHD50 1920 x 1080 49.92 1114 55.62
ü ü
WUXGA60 1920 x 1200 59.95 1235 74.04
ü ü ü
