Image menu continued from previous page
Position and Phase
Press ENTER to open a submenu.
• VGA Setup
H Total, H Start, H Phase, V Start
Adjust these settings as required to suit the incoming image.
• Digital Alignment
Digital Zoom, Digital Pan, Digital Scan
Select a digital alignment control.
Reset
Press ENTER to reset all Digital Alignment settings to zero.
• H/V Alignment
H Zoom, V Zoom, H Shift, V Shift
Select an alignment control.
Reset
Press ENTER to reset all H/V Alignment settings to zero.
Highlight the setting you wish to edit, and then press ENTER, or the LEFT or
RIGHT arrow button to open the slider.
Use the LEFT and RIGHT arrow buttons to adjust the slider.
Press MENU to close the slider.
Resync
Press ENTER to force the projector to resynchronize with the current input.
Notes
H Shift will only work if the image
has been reduced horizontally using
H Zoom. Likewise, V Shift will
only work once V Zoom has been
applied.
Image >> Position And Phase
Select Item
[Enter] Submenu
[RETURN] Back
Digital Alignment
H/V Alignment
VGA Setup
8
8
8
Image >>
Select Item
[RETURN] Back
Brightness
Contrast
Dynamic Black
Saturation
Hue
Image Mode
100
100
2.2
Off
100
Bright
Gamma
Sharpness
Noise Reduction
Position And Phase
100
15
0
8
Resync Execute
[Enter] Execute
