3D menu continued from previous page
3D types
In most situations you can use the Auto setting to have the projector automatically detect the format.
Otherwise, consider the notes below to help you set up the 3D input manually.
The following 3D formats are supported:
• Frame Packing
This format will be detected, re-synchronised, frame-multiplied and displayed at 144 Hz with the left eye /
right eye dominance automatically extracted from the video data.
• Top and Bottom
Sets the projector to reformat the video frames and map them to the display with the left eye / right eye
dominance automatically extracted from the video data.
• Side by Side (Half): interlaced and progressive, 50 and 60Hz
The side-by-side image will be de-interlaced (if appropriate), resized and then sequentially displayed at
100 or 120 Hz. The left eye / right eye dominance will be automatically extracted from the video data.
• Frame Sequential
An example of Frame Sequential would be 60Hz (30 frames per eye in Left-Right sequence (L1, R1,
L2, R2…) with 2x Frame Rate Multiplication, resulting in a displayed sequence at 120 Hz (L1, R1, L1,
R1, L2, R2, L2, R2…). For sequential 3D, the projector will generate an output sync, but it may then be
necessary to manually reset the dominance each time the player is started.
Notes
L R L R
Frame Sequential
L
R
Frame Packing
L
R
Top-and-Bottom
L R
Side-by-Side (Half)
