GETTING TO KNOW THE PROJECTOR
Rev A January 2015
Getting To Know The Projector
Front and rear views
Notes
The projector uses an infra-red
remote control.
Some of the controls are duplicated
on the projector control panel, as
shown on the next page.
 Theairltersshouldbecleanedor
changed regularly, depending on the
installation environment.
 Theltersshouldbechangedatthe
same time as the lamp is changed.
The projector lens is shipped
separately.
Lens
Connection
panel
Mains
input
Control
panel
Adjustable
foot
Front
infra-red
window
Rear
infra-red
window
Remote control
Infra-red
reception
40°
40°
Air
inlet
Air
inlet
Air
outlet
Lamp and color
wheel cover
Air lter
cover
Air lter
cover
LENS SHIFT
ZOOM
–
FOCUS
+
MENU
ENTER
RETURN
SOURCE
POWER
WARNING
LAMP1
LAMP2
AUTO
