Digital Projection E-Vision 6800 3D Series User Manual

page 18
Digital Projection E-Vision 6800 3D Series
Connection Guide
SUPPORTED SIGNAL INPUT MODES
Rev A January 2015
3D input modes
Signal Resolution Refresh Rate
( Hz )
Total
number
of lines
Horizontal
Frequency
(kHz)
HDMI /
HDBaseT
DVI-D
VGA59 Frame Sequential 640 x 480 59.94 525 31.47
ü
SVGA60 Frame Sequential 800 x 600 60.32 628 37.88
ü
XGA60 Frame Sequential 1024 x 768 60.00 806 48.36
ü
XGA120 Frame Sequential 1024 x 768 120.00 813 97.55
ü
WXGA60 Frame Sequential 1280 x 800 59.81 831 49.70
ü
WXGA120 Frame Sequential 1280 x 800 119.90 847 101.56
ü
SXGA60 Frame Sequential 1280 x 1024 60.02 1066 63.98
ü
UXGA60 Frame Sequential 1600 x 1200 60.00 1250 75.00
ü
WUXGA60 Frame Sequential 1920 x 1200 59.95 1235 74.04
ü
720p50 Frame Packing 1280 x 720 50.00 1470 37.50
ü
720p50 Side-by-Side (Half) 1280 x 720 50.00 1470 37.50
ü
720p50 Top-and-Bottom 1280 x 720 50.00 750 37.50
ü
720p50 Frame Sequential 1280 x 720 50.00 750 37.50
ü
720p120 Frame Sequential 1280 x 720 120.00 750 90.00
ü
1080i50 Side-by-Side (Half) 1920 x 1080 50.00 1125 56.25
ü
1080i60 Side-by-Side (Half) 1920 x 1080 60.00 1125 67.50
ü
1080p24 Frame Packing 1920 x 1080 24.00 2205 27.00
ü
1080p24 Side-by-Side (Half) 1920 x 1080 24.00 2205 27.00
ü
1080p24 Top-and-Bottom 1920 x 1080 24.00 2205 27.00
ü
1080p24 Frame Sequential 1920 x 1080 24.00 2205 27.00
ü
1080p50 Side-by-Side (Half) 1920 x 1080 50.00 1125 56.25
ü
1080p50 Top-and-Bottom 1920 x 1080 50.00 1125 56.25
ü
1080p50 Frame Sequential 1920 x 1080 50.00 1125 56.25
ü
continues on next page...
Notes
Only the HDMI and HDBaseT inputs
support HDMI 1.4 3D formats.

Digital Projection E-Vision 6800 3D Series Specifications
