Digital Projection E-Vision 6800 3D Series
Connection Guide
SUPPORTED SIGNAL INPUT MODES
Rev A January 2015
Supported Signal Input Modes
2D input modes
Signal Resolution Refresh Rate
( Hz )
Total
number
of lines
Horizontal
Frequency
(kHz)
VIDEO /
S-VIDEO
Component
1 & 2
VGA
HDMI /
HDBaseT
DVI (DVI-D)
SDTV 480i 720 x 480 59.94 525 15.73
ü ü
576i 720 x 576 50.00 625 15.63
ü ü
EDTV 480p59 720 x 480 59.94 525 31.47
ü ü
480p60 720 x 480 60.00 525 31.50
ü ü
576p50 720 x 576 50.00 625 31.25
ü ü
HDTV 720p50 1280 x 720 50.00 750 37.50
ü ü
720p59 1280 x 720 59.94 750 44.96
ü ü
720p60 1280 x 720 60.00 750 45.00
ü ü
1080p23 1920 x 1080 23.98 1125 26.97
ü ü
1080p24 1920 x 1080 24.00 1125 27.00
ü ü
1080p25 1920 x 1080 25.00 1125 28.13
ü ü
1080p29 1920 x 1080 29.97 1125 33.72
ü ü
1080p30 1920 x 1080 30.00 1125 33.75
ü ü
1080i50 1920 x 1080 50.00 1125 28.13
ü ü
1080p50 1920 x 1080 50.00 1125 56.25
ü ü ü
1080i59 1920 x 1080 59.94 1125 33.72
ü ü
1080p59 1920 x 1080 59.94 1125 67.43
ü ü ü
1080i60 1920 x 1080 60.00 1125 33.75
ü ü
1080p60 1920 x 1080 60.00 1125 67.50
ü ü ü
continues on next page...
