Digital Projection E-Vision 6800 3D Series
Operating Guide
USING THE PROJECTOR
Rev A January 2015
Geometry menu
This menu allows you to compensate for image distortions caused by an unusual
projection angle or irregular screen surface.
Aspect Ratio
Choose from:
• 5:4
• 4:3
• 16:10
• 16:9
• 1.88:1
• 2.35:1
• Source
• Unscaled
To change the aspect ratio:
1. From the Main menu, open Aspect Ratio.
2. From the list on the right, select a new aspect ratio and press
ENTER.
Notes
Geometry >>
Select Item
[Enter] Submenu
[RETURN] Back
H Keystone
V Keystone
Aspect Ratio
Overscan
Source
0
0
Off
Geometry >>
Select Item
[Enter] Execute
[RETURN] Back
H Keystone
V Keystone
Aspect Ratio
4:3
16:10
5:4
Overscan
16:9
1.88:1
2.35:1
Source
Unscaled
