Dinstar FXS Voice Gateway User Manual
17
WAN IP Address
Shows WAN IP address of the gateway ,
DHCP mode: all the field values for the Static IP mode are not used (even though they are
still saved in the Flash memory.) The GATEWAY acquires its IP address from the first DHCP
server it discovers from the LAN it is connected.
Using the PPPoE feature: set the PPPoE account settings. The gateway will establish a
PPPoE session if any of the PPPoE fields is set.
Static IP mode: configure the IP address, Subnet Mask, Default Router IP address, DNS
Server 1 (primary), DNS Server 2 (secondary) fields. These fields are set to zero by default.
LAN IP address
Shows LAN IP address of the gateway. if network Mode is bridge, LAN port won’t display.
DNS Server
Display DNS server IP address and default gateway information
System Uptime
Time elapsed from device power on to now.
NTP Status
Succeed: the gateway is sync to NTP server successful
Failed: failed to sync to NTP server then you should check network connection/NTP server
NTP time
Current time of the gateway
Network Traffic
Statics
Total bytes of message received and sent by network port.
Usage of Flash
Detailed usage of Flash memory
Usage of RAM in Linux
Detailed RAM usage of Linux core
Usage of RAM in AOS
Detailed RAM usage of AOS
Current Software
Version
Software version that running on the gateway. The version number consist of Model Name,
Version number, Built date
Backup Software
Version
There are two zone to storage software version. Backup software is for roll back purpose
while current software fail. The backup software version consist of Model Name, Version
number, built date
U-boot
U-boot version
Kennel version
Linux Kennel version
FS Version
File system version
