Dinstar FXS - Port Configuration

Dinstar FXS Voice Gateway User Manual
30
Heartbeat
Heartbeat message detect the connection status between device and SIP server.
Secondary SIP Server
address
Backup SIP Server’s IP address or Domain name provided by VoIP service
provider.
Secondary SIP Server
port
Service port, default is 5060
Register Expires
protects registrar against excessively frequent registration refreshes
while limiting the state. Every once in a while send request for registration to the
terminal server, default is 1800s.
Secondary SIP heartbeat
Heartbeat message detect the connection status between device and SIP server.
Outbound Proxy Address
Outbound proxy IP address or Domain name provided by VoIP service provider.
Outbound Proxy Port
Default outbound proxy SIP service port is 5060.
Retry Interval when
Registration failed
The retry interval time after the registration failed last time
Registration times per
second
Limit the gateway to send REGISTER messages per second
SIP Transport Type
The SIP transport type, can be UDP, TCP, Auto; default to UDP
Use Random Port
Random SIP service ports for gateway
SIP Local Port
Default SIP local service port is 5060.
Port Configuration
Port parameters include: Send gain, receive gain, primary display name etc.
