Dinstar FXS Voice Gateway User Manual
52
Index
Port group Number, It uniquely identifies a route, range from 0-7
Description
Port group description, its purpose is so you can identify the port
group with a meaningful name
Primary/Secondary Display Name
Port group display, which will be used in SIP message, example:
INVITE sip:bob@biloxi.com SIP/2.0
Via:SIP/2.0/UDPpc33.atlanta.com;branch=z9hG4bK776asdhds
Max-Forwards: 70
To: Bob <sip:bob@biloxi.com>
From: Alice <sip:alice@atlanta.com>;tag=1928301774
Here Bob and Alice is the display
Primary/Secondary SIP User ID
User account information, provided by VoIP service provider
(ITSP). Usually in the form of digit similar to phone number or
actually a phone number.
Primary/Secondary Authenticate
ID
SIP service subscriber’s Authenticate ID used for authentication.
Can be identical to or different from SIP User ID.
Primary/Secondary Authenticate
Password
Password of SIP user ID
Offhook Auto-Dial
Offhook auto-dial number
Auto-dial Delay time
Delay time before dialing
Port Select
 It specifies the policy for selecting port in a port group
 Ascending: the system always selects a port from the minimum
number. The preferential selection of the port can be realized
through this mode
 Cyclic ascending: when system selects ports’ Priority, it always
begin from the number next to the number selected last time,
if the maximum priority number is selected last time, then the
next number is the minimum priority number, and move in
cycles like this
