ICS-90 Ion Chromatography System
2-2 Doc. 031851-05 12/04
2.1 Operating Features
2.1.1 Front Door and Top Cover
Figure 2-1 illustrates the front door and top cover of the ICS-90.
The front door contains a sample injection port and LEDs that indicate the
ICS-90 operating status. The top cover is molded to hold the eluent and
regenerant reservoirs.
LEDs
There are three status LEDs on the ICS-90 front
panel. Other status information and alarm
messages are displayed in Chromeleon software.
See Section 4.1
for a description of the software
alarm messages.
Injection Port
The sample to be analyzed is injected into the injection port, using either a
syringe or the optional AS40 Automated Sampler. For more information
about sample injection, see Section 3.5.6
.
LED Label If On (Green) If Flashing
Power ICS-90 power is on Does not flash
Ready System check passed, but
sequence not yet started
(LED stays on until run starts
or sequence is aborted)
System check failed (occurs if
system check executes for
10 minutes without success)
Run Running/acquiring data Error/alarm/fault (including
injection valve position)
Power
Ready
Run
