Doc. 031851-05 12/04 5-1
5•Service
This chapter describes routine service procedures that users may perform. Other
service procedures must be performed by Dionex personnel.
NOTE The ICS-90 Ion Chromatography System electronics
components cannot be serviced by the user. Repair of
electronics components must be performed by Dionex.
Before replacing any part, refer to the troubleshooting information in Chapter 4 to
isolate the cause of the problem. When ordering replacement parts, please include
the ICS-90 model number and serial number. To contact Dionex in the U.S., call
1-800-346-6390. Outside the U.S., call the nearest Dionex office.
Substituting non-Dionex parts may impair ICS-90 performance, thereby voiding
the product warranty. Refer to the warranty statement in the Dionex Terms and
Conditions for more information.
5.1 Diagnostics and Calibrations
Chromeleon allows you to perform diagnostic and calibration procedures and to
monitor ICS-90 functions from the Wellness panel (see Figure 5-1
). This section
provides an overview of Wellness panel features. For instructions on performing
calibrations, see the following sections:
• Calibrating the Pressure Transducer (Section 5.1.1)
• Calibrating the Cell (Section 5.1.2)
To open the Wellness panel:
1. Open the Chromeleon Browser and expand the Dionex Templates folder.
2. Expand the Panels folder and then the Wellness folder.
3. In the right pane of the Browser window, double-click Dionex_ICS-
90_wellness.pan.The Wellness panel appears.
