ICS-90 Ion Chromatography System
2-16 Doc. 031851-05 12/04
Figure 2-9. Chromeleon Browser
2.3.2 The ICS-90 Control Panels
Chromeleon provides two kinds of Control panels for the ICS-90. System
Control panels (see Figure 2-10
) are used for controlling and monitoring
ICS-90 operation. Wellness panels are used for performing calibration
and diagnostic functions. Section 5.1
describes the Wellness panels.
Figure 2-10. System Control Panel (ICS-90 with an AS40)
