ICS-900 Operator’s Manual
92 Doc. 065215-02 9/09
5.13 Changing the Main Power Fuses
1. Turn off the ICS-900 power switch.
2. Disconnect the power cord.
3. The fuse drawer is located above the
power switch (see Figure 5-16
). A small
tab locks the fuse drawer in place. Using
a small screwdriver, press the tab in and
then up to release the fuse drawer.
4. Pull the fuse drawer out of the rear panel
and remove the old fuses.
5. Replace the two fuses with new fast-blow
IEC 127 fuses rated 3.15 A
(P/N 954745). Dionex recommends
always replacing both fuses.
Figure 5-16. Fuse Drawer
6. Insert the fuse drawer into the rear panel and press until the drawer snaps into
place.
7. Reconnect the main power cord and turn on the power.
HIGH VOLTAGE—Disconnect the main power cord from its source and
also from the rear panel of the ICS-900.
HAUTE TENSION—Débranchez le cordon d'alimentation principal de
sa source et du panneau arrière du ICS-900.
HOCHSPANNUNG—Ziehen Sie das Netzkabel aus der Steckdose und
der Netzbuchse auf der Rückseite des ICS-900.
Fuse
Drawer
Tab
