2 • Description
2.1 Operating Features
2.1.1 Front Door and Top Cover
Figure 2-1 illustrates the front door and top cover of the ICS-900 Ion
Chromatography System (ICS-900).
Figure 2-1. ICS-900 Ion Chromatography System
Status LEDs
Injection
Port
Regenerant
Bottle
Eluent Bottle
