Dirui CS-T240 - Page 14

14
Barcode information
type：code 128
Size：
width: 8-12mm; alid length : within
40mm; start blank and finish blank:
within 3mm when cutting.
Sticking requirement:the lower edge of barcode
should be within 15mm-20mm away from the
test tube bottom
to make sure right reading
barcode,and make sure the barcode is aligned
with sample position gap when putting the test
rack.
Reacti
on System
Reaction cuvette mode Discrete
Reaction cuvette
optical path
6mm
Reaction cuvette number
6 sets, 20 for each，total 120
Reaction time 15 mins
Reaction liquid volume
150～550ul
Light source 20W/12V Long-life quartz halogen lamp
Absorbance range
0～3.3ABS
QC QC interval, monthly QC
Automatic rinsing
Automatically rinsing reaction cuvette, sample&
reagent probe, stirring rod.
Stirring system separately stirring after adding
Data
system
port
TCP/IP network port，standard RS-232 and USB
2.0 port
Printer
Stylus printer, supporting the user-defined mode
for report sheet
Connecting LIS/HIS system LIS/HIS system available
Instrument
system
weight About 120Kg
Dimensions 998*752*515 (length×width×height)
