Dirui CS-T240 - 1.1.2 Front Panel Components; 1.1.3 Rear Panel Components

3
1.1.2 Front ① ②
① Model Logo
② Upper Cover
③ Front Cover
③
1.1.3 Rear
① Purified Water Inlet
② Low Concentrate Waste Outlet
③ High Concentrate Waste Outlet
④ Detergent Inlet
⑤ Detergent Level Sensor Port
⑥ Left Back Cover
⑦ Syringe Pump
⑧ Right Back Cover
⑨ R S232 Port
① ②③ ④ ⑤ ⑥ ⑦
⑧ ⑨
