Dirui CS-T240 - Colorimetric Cup Rinsing Mechanism; Rack; Main Rack Configuration

31
4.6 Colorimetric cup rinsing mechanism
4－20
Only one-dimensional movementavailable to colorimetric cup rinsing mechanism,and driving
mechanism adopts the up-down driving mechanism of stirring rod.
4.7 Rack
Rack includes the main rack, electrical, gas liquid valve and water tanks and other racks.
4－21 Main rack configuration
Up-down step motor
Up-down
slider
Colorimetric
cup rinsing
probe
Rinsing probe
rack
of
colorimetric cup
Bottom-Board
Main working table board
Adjusting foot
Isolating
standing
board
