1.1.4 Working Table

① Reaction Cuvette Rinsing Unit

② Reaction Disk Unit ① ② ③ ④ ⑤ ⑥

③ Reaction Tank Liquid Level Detection

④ Stirring Unit

⑤ Sample &Reagent Adding Unit

⑥ Sample & Reagent Disk

⑦ Mixer Rinsing Tank

⑧ Probe Rinsing Tank

⑦ ⑧

1.1.5 Rightside

① Main Switch

② Power Socket

③ Fuse Installation Place

④ Main Power Indicator（Red）

⑤ Refrigeration Power Indicator（Green）

⑥ Analysis Unit Switch（exclude refrigeration power）

① ② ③ ④ ⑤ ⑥
