Chapter 5. Instrument Fluid Pipeline
5.1 Main function of liquid line
The CS-T240 liquid line system can be divided into four parts: water inlet tank, 37 degrees
centigrade temperature, colorimetric cup cleaning, the inner and outer arms and stirring rod
cleaning.
1. CS-T240 liquid line system includes sampling subsystem and cleaning subsystem.
2. Sampling subsystem uses one probe plus one stirring rod and one injector. The injector use
500uL
3. The inner and outer wall cleaning of probe and stirring rod uses barotropic driving.
4.Cleaning bath: two cleaning bathes plus waste liquor in the reagent
storehouse, together
with the flooding waste liquor in the reaction disk etc.
5. The reaction cuvette cleaning uses the way named 8-stop 12-step.
6.Water supply: uses the special outboard water-supply equipment and the special
water-supplying machine.
7. Waste liquor: reticulate pattern pipe as low concentrate waste pipe with inside diameter of
12mm, wall thickness 3mm, high concentrate waste pipe is also reticulate pattern pipe with inside
diameter is 8mm and wall thickness is 2mm
8. Source of power: the power of cleaning comes from the magnetic pump..
9. The cleaning of reaction cup should use one detergent..
10. The vacuum degree for vacuum pump assimilating≥
-70kPa
11. The inner and outer wall cleaning of probe uses independent solenoid valve while the
stirring rod use one solenoid valve.
